Maintenance free

Belt lifetime is semi-permanent.
This machine does not need a submerged bearing part, vertical drip pulley, support shaft.
Thus, there are no troubles occurring from these parts.

heat resistance and corrosion resistance

Because it is a belt made of sinless steel wire, it is excellent against temperature and corrosion.

adjustable belt length

The length of the belt will be easily adjustable at site, there is no seam trouble.

A wide range of structure

Optimum structure for scum property, suspended matter concentration, oil type etc. are available.

Product blueprint

  • In the mesh skimmer, the surface tension of the liquid acts on the mesh belt and is supplemented, detached on the surface of the rotating drum, there collect oil.
    Depending on the viscosity of the liquid, it is decided appropriate and unfriendly.
    Based on various test results, our standard specifications are belt eye gauge and speed with the most recovered amount under machine oil, oil film thickness 10mm, oil temperature 20℃.

Standard size chart

Type OS-75HS OS-150HS OS-300HS
Mesh Belt Width 75 150 300
Recovery Ability 50 100 200
Main Dimension 330×330×360 330×400×360 350×580×410
Mounting dimensions 370×240 370×310 390×490
Standard effective belt length 400 400 350
Weight (Kg) 20 25 45



  • SUNTECHNO have manufactured not only Mesh Skimmer but also other various industrial dust/mist collectors and white smoke apparatus since our founding in 1974.
  • Each of them can be customized based on user conditions. We can propose for suitable place to be installed, modification of duct, cost reduction if you contact us.

Please feel free to contact us
if you have any questions.
